SPECIFICATIONS

Brand Name: DIXSG

High-concerned chemical: None

Origin: Mainland China

Type: Other Module

Feel free to reach out to us if you require customized samples for testing, intend to place bulk orders once samples are approved, or need faster shipping options including DHL and UPS.

We can communicate more details and offer bulk quotations based on your order volume.

Only the Transmitting Channel (TX)

Note

1.The white line is the module switch control line, which controls the opening and closing of the module. After the white wire is powered on, the module opens

The white and red lines connect positive pole of the power supply（+）

the black line represents the negative pole of the power supply（-）

If you don't need the white line control module to turn on and off, you can let us know and we can remove the white control line for you

2.In order to ensure stable module performance, please add heat sinks and fans for forced cooling in the module to ensure long-term stable operation.

3.Before powering on the module, please confirm whether the module connector is connected to the antenna

4.This module has high average output power, good in-band flatness and the small offset between upper and lower side band. The frequency band and output power of the module can be customized according to customer needs.

5.This is passive signal source module,This RF power amplifier has no signal source build in

6.The input source should not exceed the standard input, which can easily cause the module to be unable to withstand and burn out. We suggest adding an attenuator to attenuate the inputEach moduleis labeled with a standard input on the outside

7.We can provide testing videos of the modules before shipment. If you need them, you can contact our staff to send them to you before shipment

8.Thismodule is suitable for multiple fields. For any application or technical issues, please feel free to contact us at any time
