SPECIFICATIONS

AI Functions: Motion Detection

Alarm Action: Email Photo

Brand Name: HIKVISION

Certification: CE

Color: WHITE

Connectivity: IP/Network Wired

Dimensions (L x W x D)(mm): 26*26*22

HIKVISION Model: DS-2DE4A425IWG-E

High Definition: 4.0 Megapixels

High-concerned chemical: None

IP Rating: IP66

IR Distance(m): up to 50M

Installation: ceiling

Lens (mm): 4.7-94mm

Lens Quantity: Single Lens

Megapixels: 4MP

Model Number: DS-2DE4A425IWG-E

Operating Temperature: -10°-60°

Origin: Mainland China

Power Consumption(W): Max 18W

Power Supply: With Poe

Power Supply(V): 12V

Scene: Indoor and outdoor

Sensor: CMOS

Shell Material: Metal

Special Features: Waterproof / Weatherproof

Style: Dome Camera

Supported Mobile Systems: Windows Mobile,Android,iOS

Supported Operating Systems: Windows 7,macOS,Windows 8,Windows 10

TF Card: None

Video Compression Format: H.264,H.265

Whether or Not 50Vac or 75Vdc or Higher Power Supply: No

Zoom: NONE

Zoom type: None

is_customized: No

Item Name:  DS-2DE4A425IWG-E replace DS-2DE4A425IW-DE

Feature:

High quality imaging with 4 MP resolution, up to 30 fps

Excellent low-light performance via powered-by-DarkFighter technology

Clear imaging against strong back lighting due to 120 dB WDR technology

Pan and tilt ability enables camera to monitor zones of interest

25 × optical zoom allows for closer viewing of subjects in expansive areas

Up to 50 m IR range ensures safety at night

Water and dust resistant (IP66)

Focuses on human and vehicle targets classification based on deep learning

• Camera

• Image Sensor1/2.8" Progressive Scan CMOS

• Max. Resolution2560 × 1440

• Min. IlluminationColor: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR

• Shutter Speed1/1 s to 1/30,000 s

• Day & NightIR cut filter

• Zoom25 × optical, 16 × digital

• Slow ShutterYes

• Lens

• Focal Length4.8 to 120 mm

• FOVHorizontal FOV 53.3° to 2.6°, vertical FOV 30.6° to 1.5°, diagonal FOV 60.5° to 3°

• FocusAuto, semi-auto, manual

• ApertureMax. F1.6

• Zoom SpeedApprox. 3.4 s

• Illuminator

• Supplement Light TypeIR

• Supplement Light RangeIR Distance: up to 50 m

• Smart Supplement LightYes

• IR Wavelength850 nm

• PTZ

• Movement Range (Pan)0° to 360°

• Movement Range (Tilt)-5° to 90°

• Pan SpeedPan speed: configurable from 0.1° to 300°/s; preset speed: 350°/s

• Tilt SpeedTilt speed: configurable from 0.1° to 160°/s, preset speed 200°/s

• Proportional ZoomYes

• Presets300

• Preset FreezingYes

• Patrol Scan8 patrols, up to 32 presets for each patrol

• Pattern Scan4 pattern scans, record time over 10 minutes for each scan

• Park ActionPreset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan

• 3D PositioningYes

• PTZ Status DisplayYes

• Scheduled Taskpreset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust

• Power-Off MemoryYes

• Video

• Main Stream

  50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

  60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

• Sub-Stream

  50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288);

  60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

• Third Stream

  50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);

  60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

• Video Compression

  Main stream: H.265+/H.265/H.264+/H.264

  Sub-stream: H.265/H.264/MJPEG

  Third stream: H.265/H.264/MJPEG

• H.264 TypeBaseline Profile/Main Profile/High Profile

• H.265 TypeMain profile

• Scalable Video Coding (SVC)H.264 and H.265 encoding

• Region Of Interest (ROI)8 fixed regions for each stream

• Audio

• Audio CompressionG.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM/AAC-LC

• Audio Bit Rate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/128 to 1024 Kbps (PCM)/16 to 64 Kbps (AAC-LC)

• Audio Sampling RateAAC-LC: 16 kHz, 32 kHz, 48 kHz; MP2L2: 16 kHz, 32 kHz, 48 kHz; PCM: 8 kHz, 16 kHz, 32 kHz, 64 kHz

• Environment Noise FilteringYes

• Network

• ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets

• Simultaneous Live ViewUp to 20 channels

• APIOpen Network Video Interface (Version 18.12), Profile S, Profile G, Profile T), ISAPI, SDK, ISUP

• User/HostUp to 32 users; 3 user levels: administrator, operator, and user

• SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address)

• Network StorageNAS (NFS, SMB/CIFS), auto network replenishment (ANR)

• ClientiVMS-4200, HikCentral Pro, Hik-Connect

• Web BrowserIE 10 to 11, Chrome 57+, Firefox 52+, Safari 11+

• Image

• Image Parameters SwitchYes

• Image SettingsSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser

• Day/Night SwitchDay, Night, Auto, Schedule

• Wide Dynamic Range (WDR)120 dB

• SNR＞52 dB

• DefogDigital Defog

• Image EnhancementBLC, HLC, 3D DNR

• Privacy Mask24 programmable polygon privacy masks, mask color or mosaic configurable

• Regional FocusYes

• Regional ExposureYes

• Interface

• Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port

• On-Board StorageBuilt-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB

• Audio

  1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%;

  1 output (line out), line level, output impedance: 600 Ω

• Alarm2 inputs, 2 outputs

• ResetYes

• Event

• Basic EventMotion detection, video tampering alarm, exception, alarm input and output

• Smart Eventline crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection

• Alarm LinkageUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan)

• Smart TrackingManual tracking, auto-tracking

• Deep Learning Function

• Face Capture

  Detects up to 5 faces simultaneously,

  Supports detecting, tracking, capturing, grading, selecting of face in motion, and outputs the best face picture

• General

• Power12 VDC, Max. 24 W; PoE (802.3at)

• DimensionØ 169 mm × 161 mm (Ø 6.65" × 6.34")

• WeightApprox. 2.45 kg (5.40 lb.)

• Operating Condition-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)

• General FunctionMirror, password protection

• Approval

• ProtectionIP66 (IEC 60529-2013), TVS 6000V lightning protection, surge protection and voltage transient protection
